GENERAL INFORMATION
• Manufacturer: Mori Seiki
• Model: NH-6300DCG II
• Year: 2011
• Machine Type: CNC Horizontal Machining Center
• Condition: Very Good
• Stock Number: 55063

SPECIFICATIONS
• CNC Control: MSX-701IV / FANUC 31i MAPPS IV
• Number of Axes: 4
• Spindle Speed: 8,000 RPM
• Spindle Taper: CAT 50
• Main Motor: 50 HP (High Torque Option)

• X-Axis Travel: 41.3″
• Y-Axis Travel: 35.4″
• Z-Axis Travel: 38.6″

• Rapid Traverse (X/Y): 1968.5 IPM
• Rapid Traverse (Z): 1574.8 IPM

• Pallet Size: 24.8″ x 24.8″
• Pallet Capacity: 3,300 lbs
• Pallet Indexing (B-Axis): 1 Degree
• Max Workpiece Height: 51.1″

• Tool Changer Capacity: 120 ATC
• Max Tool Length: 24.8″
• Max Tool Diameter (adjacent): 4.3″
• Max Tool Diameter (no adjacent restriction): 12.5″
• Max Tool Weight: 66 lbs

• Machine Hours:
– Power On: 45,907 hrs
– Operation Time: 14,242 hrs
– Cutting Time: 11,608 hrs

CONTROL SYSTEM
• MSX-701IV CNC Control / FANUC 31i MAPPS IV

PALLET SYSTEM
• 10-Pallet Pool System with Load/Unload Station
• 24.8″ x 24.8″ Pallets
• Fully automated pallet handling system for high productivity

EQUIPPED WITH
• 10-Pallet CPP Pallet Pool System
• 120-Position Automatic Tool Changer
• 1,000 PSI High Pressure Coolant System (Chip Blaster)
• Through-Spindle Coolant
• Renishaw OMP60 Spindle Probe
• Tool Breakage Detection System
• Coolant Gun for Setup Station
• Chip Conveyor
• Rigid Tapping Capability
• Tool Life Management System
• Coolant Filtration System
• Additional Work Coordinate System (300 sets memory)

FEATURES
✓ High-production 10-pallet automation system for continuous operation
✓ Powerful 50 HP spindle with high torque output for heavy-duty machining
✓ Advanced 120-tool ATC for complex and flexible tooling setups
✓ Integrated probing and tool monitoring for precision and reliability
✓ High-pressure coolant system improves tool life and chip evacuation
✓ Designed for lights-out manufacturing and long production runs
✓ Robust Mori Seiki construction for maximum stability and accuracy

APPLICATIONS
• High-volume production machining
• Automotive and aerospace components
• Complex multi-operation parts
• Precision industrial manufacturing
• Automated palletized production systems
• Long-cycle unattended machining operations
