GENERAL INFORMATION
• Manufacturer: Davis-Standard
• Model: Thermatic 45IN45T
• Year: 2008
• Machine Type: Plastic Sheet Co-Extrusion Line
• Condition: Used

SPECIFICATIONS
• Maximum Extrusion Width: 1,650 mm
• Maximum Sheet Thickness: 15 mm
• Extrusion Head Width: 2,000 mm
• Main Extruder Motor: 187.5 kW @ 380V
• Total Installed Capacity: 329 kW
• Roll Diameter: 405 mm
• Cooling Roll Width: 1,650 mm

PRODUCTION CAPACITY
• Designed for production of ABS, EPDM & PE sheets
• Co-extrusion capability for different top and bottom layers
• Annual production (2 lines): Approx. 1,700,000 kg

SYSTEM CONFIGURATION
• Main Extruder: Davis-Standard 45 IN 45 HT
• (2) Davis-Standard 15-IN-20 Co-Extruders
• 2 Extrusion Stations for Sheet Production

EQUIPPED WITH
• 2,000 mm extrusion die/head
• Roll stack with inclination roll and cooling system
• Multiple relief rolls
• Haco 2,000 mm automatic flying shear
• Dosing plant
• Automatic product evacuation system

FEATURES
✓ Complete co-extrusion line for manufacturing multi-layer plastic sheets
✓ Produces ABS, EPDM, and PE sheets with different top and bottom surface layers
✓ Wide 1,650 mm production width for high-output manufacturing
✓ Heavy-duty Davis-Standard extrusion technology recognized worldwide
✓ Automatic flying shear and product handling improve production efficiency
✓ Integrated dosing and cooling systems for consistent product quality
✓ Excellent solution for continuous industrial sheet extrusion

APPLICATIONS
• ABS sheet production
• PE sheet manufacturing
• EPDM sheet production
• Multi-layer plastic sheet extrusion
• Industrial plastic fabrication
• Automotive and construction plastic products
